Max.swing over bed (mm): 410
Max.cutting dia.for disc parts (mm): 260
Max.cutting dia. for axe parts (mm): 200
Maximum turned length (mm): 350
Max.cross trave (X) (mm): 180
Max.omgitudina trave (Z) (mm): 420
Rapid feed for axis X (m/min): 9
Rapid feed for axis Z (m/min): 15
Max.speed of spindle (rpm): 3000 / chuck 200
4000 / chuck 160
Diamrter of spindle thru hoe (mm): φ63
Spinde nose: A2-5
Hydrauic chuck (mm): 8"
Number of toos: 8
Outside dia.Of cutting too shank (mm): 20x20
Inner dia. Of cutting too shank (mm): 25
Taistock seeve dia. (mm): φ63
Taistock seeve trave (mm): 100
taistock center type: MT4
Min.Input (mm): 0.001
Servo motor power for x axis (NM): 7
Servo motor power for z axis (NM): 7
Slant bed integrated with stand: 60˚
Guide ways X & Z: Precision linear guides
Repeatability (X/Z): 0.005 / 0.006
Surfacce roughness: ≤Ra0.8mm (Nonferrous) ≤Ra1.6mm (Stee part)
Capacity for cooant (L): 100
Main motor power (KW): 5.5 inverter
Overa dimension mode (LxWxH) (cm): 243x127x166
Net weight (kg): 2700
Standard Accessories: Total sealed fencing system; Lubrication system; solid hydraulic chuck; Optional manual
Optional Accessories: Hollowed hydraulic chuck; Automatic conveying system; Hydraulic tailstock
