Table size (mm): 240 x 810
T slots (N x W x D) (mm): 3 x 14 x 54
Longitudinal travel X (mm): 480
Cross travel Y (mm): 165
Vertical travel Z (mm): 300
Max. rotary angle of table: ±45°
Arbor diameter (mm): Ø22 Ø27
Min. distance between spindle center to talbe (mm): 60
Spindle hole taper: MT3 or 30# 7:24
Spindle speed steps: 6
Spindle speed ranges (r/min): 31-570
Distance between spindle center to arm (mm): 160
Feed speed steps: 6
Feed speed ranges
Longitudinal X (mm/min): 7.3-111.9
Cross Y (mm/min): 14.9-226.3
Vertical Z (mm/min): 6-90.4
Main motor power (kw): 1.5
Main motor speed (r/min): 1430
Cooling pump power (kw): 0.12
Overall size (mm): 1400 x 1240 x 1478
Packing box size (mm): 1500 x 1340 x 1760
Net weight (Kg): 1200
Standard Accessories: Milling arbors; Tools; Draw-bolts; Manuals
Optional Accessories: Universal milling head; Rotary table; Machine vice; Milling chuck collets
