CAPACITY
Max.swing over bed: Ф520mm
Max.cutting diameter for disc parts: Ф420mm
Max.cutting diameter for axle parts: Ф250mm
Max. cutting length: 500mm
TRAVEL
X travel: 255mm
Z travel: 540mm
FEED
Travel speed for axis X/Y/Z: 30m/min
Feed speed for axis X/Y/Z: 30m/min
SPINDLE
Max.speed of spindle: 4000rpm/ 5000rpm(sleeve spindle)
Spindle nose: A2-6
Diameter of spindle bore: Ф65mm
Hydraulic chuck: 8″
Spindle motor power: 11/15kw
TOOL POST
Tool number: 12 ways hydraulic turret
Outside diameter of cutting tool shank: 25×25mm
Inner dia.of cutting tool shank: Ф40mm
TAILSTOCK
Tailstock sleeve dia.: Ф80mm
Tailstock sleeve travel: 120mm
Taper hole of tailstock quill: M.T.No.4
OTHERS
Bed structure: 45° slant bed integrated with stand
Overall dimensions(L×W×H): 4500×1850×2000mm
Net weight: 4300kg
