Number of inputs: 4
Function: Inverting, non-inverting or off
Gain: 1×
Impedance: 1 MΩ
Bandwidth: DC to 1 MHz
Output noise: 60 nV/√Hz at 1 kHz
Crosstalk: −80 dB at 1 kHz
Offset: ±100 µV (after 5 min. warm up)
Max. input & output: ±10 V
Input slew rate: 40 V/µs
THD: 0.01 % (80 dB) at 1 kHz
Output slew rate: 75 V/µs
Operating temperature: 0 °C to 40 °C (non-condensing)
Interface: Serial via SIM interface
Connectors: BNC (5 front-panel, 1 rear-panel); DB15 (male) SIM interface
Power (max.): Power supplied by the SIM900 Mainframe, or optionally by a user-supplied DC power supply (±15 V and +5 V).
Dimensions: 1.5" × 3.6" × 7.0" (WHL)
Weight: 1.5 lbs.
