Polarity: Positive
Tolerance: 2.5 %
Output Type: Fixed
Unit Weight: 10 mg
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Output Current: 200 mA
Output Voltage: 5 V
Dropout Voltage: 700 mV
Line Regulation: 0.01 %/V
Load Regulation: 2 mV
Number of Outputs: 1 Output
Quiescent Current: 220 uA
Moisture Sensitive: Yes
Input Voltage - Max: 40 V
Input Voltage - Min: 3.3 V
Dropout Voltage - Max: 1 V
Operating Temperature Range: - 40 C to +150 C
Voltage Regulation Accuracy: 2.5 %
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
PSRR / Ripple Rejection - Typ: 70 dB
