Shutdown: No Shutdown
Output Type: Rail-to-Rail
Qualification: AEC-Q100
Mounting Style: SMD/SMT
SR - Slew Rate: 600 mV/us
THD plus Noise: 0.005 %
Number of Channels: 2 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 30 nA
Operating Supply Current: 375 uA
Ios - Input Offset Current: 10 nA
Output Current per Channel: 45 mA
Vos - Input Offset Voltage: 1 mV
GBP - Gain Bandwidth Product: 1.7 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
CMRR - Common Mode Rejection Ratio: 135 dB
PSRR - Power Supply Rejection Ratio: 124 dB
