Gain: 4.82 dBi, 4.94 dBi, 5.06 dBi, 5.08 dBi, 4.15 dBi
Style: Square
Width: 45 mm
Height: 10 mm
Length: 45 mm
Impedance: 50 Ohms
Cable Type: 1.37mm Coaxial Cable
Application: Wearables, Navigation
Cable Length: 100 mm
Polarization: RHCP
Mounting Style: PCB Mount
Frequency Range: 1.166 GHz to 1.61 GHz
Number of Bands: 5 Band
Mechanical Style: Square
Maximum Frequency: 1.61 GHz
Minimum Frequency: 1.166 GHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
