Gain: 3 dBi
VSWR: 1.2:1
Style: Round Flexible
Width: 37 mm
Height: 0.15 mm
Length: 38 mm
Impedance: 50 Ohms
Cable Type: 92 mm RF1.37
Application: Positioning Accuracy
Unit Weight: 249.480 g
Cable Length: 92 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 1.561 GHz, 1.575 GHz, 1.602 GHz
Mechanical Style: PCB Trace
Ground Plane Size: 30 cm x 30 cm
Maximum Frequency: 1.61 GHz
Minimum Frequency: 1.559 GHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF1
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS, IRNSS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
