Gain: - 2.4 dB
Style: T-Pad Flex
Width: 50.4 mm
Height: 0.2 mm
Length: 120.4 mm
Frequency: 600 MHz to 6 GHz
Impedance: 50 Ohms
Cable Type: 150 mm RF1.37
Application: Ultra Wide-band Application
Cable Length: 150 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Frequency Range: 600 MHz to 6 GHz
Number of Bands: 9 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1400 MHz, 1575.42 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 2600 MHz, 3500 MHz, 5400 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 6 GHz
Minimum Frequency: 600 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: I-PEX MHF 4L
Protocol - GPS, GLONASS: Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
