Gain: 5 dBi
VSWR: 2:1, 2:1, 1.8:1, 1.7:1, 1.7:1, 2.3:1
Style: T-Bar Flex
Width: 21 mm
Height: 0.2 mm
Length: 182 mm
Impedance: 50 Ohms
Cable Type: 150 mm RF1.37
Technology: Cellular, LTE, MiMo
Application: Wide-band Application
Unit Weight: 3.400 g
Cable Length: 150 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1575 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2300 MHz, 2400 MHz, 2600 MHz, 2500 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 3 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: IPEX MHF1
Protocol - GPS, GLONASS: Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA, GPRS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
