Gain: 1.2 dBi, 3.2 dBi, 2.5 dBi, 1.5 dBi
VSWR: 3.0:1
Style: Dome
Length: 48 mm
Diameter: 50 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: RG316
Application: Cellular Application
Unit Weight: 66 g
Cable Length: 1 m
Polarization: Linear
Power Rating: 5 W
REACH - SVHC: Details
Mounting Style: Direct / Permanent Mount
Number of Bands: 4 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2650 MHz, 2450 MHz
Mechanical Style: Module
Ground Plane Size: 30 cm x 30 cm
Maximum Frequency: 2.8 GHz
Minimum Frequency: 700 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA, GPRS, EDGE, IMT
