Gain: 1.8 dBi
Style: Stubby
Width: 17.2 mm
Length: 28.1 mm
Diameter: 7.8 mm
Bandwidth: 100 MHz
IP Rating: IP65
Impedance: 50 Ohms
Technology: Monopole
Application: Wireless Application, ISM Application
Unit Weight: 7.326 g
Polarization: Vertical
Power Rating: 1 W
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
