Gain: 2.1 dBi, 2.9 dBi, 3.8 dBi, 2.8 dBi
VSWR: 1.7:1, 2, 2
Style: Dome
Length: 82.4 mm
Diameter: 143.2 mm
Bandwidth: 10 MHz
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 3 M RG174, 3 M CFD200 x 2
Technology: Cellular, GPS, LTE, WiFi, MiMo
Application: Public Safety, Passenger Bus, Rail Services, Digital Signage, Commercial Transportation, Fleet Management
Cable Length: 3 m
Polarization: Linear - Vertical
Mounting Style: Direct / Permanent Mount
Electrical Type: Active
Number of Bands: 4 Band
Center Frequency: 657 MHz, 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1474 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 2600 MHz, 3400 Mhz, 5200 MHz, 5500 MHz, 5800 MHz, 1575 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 5.9 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male, SMA Male
Protocol - GPS, GLONASS: Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
