VSWR: 3, 3
Style: Panel
Width: 134 mm
Height: 20 mm
Length: 146 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 3 M RG174, 3 M KSR200-P
Application: IoT Gateway, Routers, HD Video Streaming, Transportation
Cable Length: 3 m
Polarization: Linear
Mounting Style: Bracket Mount
Electrical Type: Active
Number of Bands: 6 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 2500 MHz, 3500 MHz, 5200 MHz, 5800 MHz, 1575.42 MHz, 1561.098 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 5.85 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male, SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS, IRNSS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, GPRS, WCDMA, HSPA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
