Gain: 5 dBi
VSWR: 2
Style: Ceramic
Width: 25 mm
Height: 4 mm
Length: 25 mm
Bandwidth: 85 MHz
Impedance: 50 Ohms
Application: Wireless Application
Unit Weight: 1 g
Polarization: Linear
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Patch
Ground Plane Size: 50 mm x 50 mm
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Pin
Protocol - Sub GHz: IoT, ISM
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiMAX
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
