Characterized frequency range: 5 MHz – 3 GHz
Comb spectrum flatness up to 1.5 GHz, amplifier off: typically 8 dB at the RF connector
Comb spectrum flatness up to 1.5 GHz, amplifier on: typically 12 dB at the RF connector
Output impedance: 50 Ohm
Output power: -5 dBm max. @ 100 MHz f comb; decreasing 6 dB with every fcomb/2
Amplitude stability: < 0.2 dB; <0.1 dB after 15 minutes
Aging: < 0.5 dB over 12 months
Output connector: N-female
Selectable, fixed comb frequencies: 100 MHz, 50 MHz, 25 MHz, 10 MHz, 5 MHz
Frequency stability: 50 ppm
External excitation input: 5 kHz – 200MHz @ square input signal; 3.3 Vpp max,100 kHz – 200 MHz @ sinus input signal; 3.3 Vpp max
External input impedance: 50 Ohm
Input connector: SMA-female
Indicators: Power On LED, Low Battery LED
Power supply: 6 x AA NiMH (e.g. Varta Mignon 2700, not supplied)
Charger: external; Ansmann ACS310
Antennas: 30 cm monopole for f<300 … 500 MHz; 10 cm monopole for f>300…500 MHz
Operation time: battery capacity / 96 mA (ampl. off) or 181 mA (ampl on)
Temperature range: -10°C to +45 °C; lower operating temperature depending on batteries
Housing diameter: 180 mm
Housing height: 60 mm
Weight: 1250 g
