Shutdown: No Shutdown
Input Type: Rail-to-Rail
Technology: Zero-Drift
Output Type: Rail-to-Rail
Amplifier Type: Differential
Mounting Style: SMD/SMT
SR - Slew Rate: 40 V/us
THD plus Noise: 0.00012 %
Number of Channels: 2 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 4.5 V
Ib - Input Bias Current: 50 pA
Operating Supply Current: 1.5 mA
Ios - Input Offset Current: 100 pA
Output Current per Channel: 42 mA
Vos - Input Offset Voltage: 3 uV
Maximum Dual Supply Voltage: 18 V
Minimum Dual Supply Voltage: 2.25 V
GBP - Gain Bandwidth Product: 14 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 175 fA/sqrt Hz
en - Input Voltage Noise Density: 7.6 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 118 dB
PSRR - Power Supply Rejection Ratio: 150 dB
