Channel: 2 (4/6 Ch Optional)
Display
+ Display: 10.1-inch capacitive touchscreen
+ Ratio: 0.672916667
+ Resolution: 1280*RGB*800
Test Parameter: Ciss, Coss, Crss, Rg. Four parameter selectable arbitrarily
Test Frequency
+ Range: 1kHz-2MHz
+ Accuracy: 0.0001
+ Resolution: 10mHz 1.00000kHz-9.99999kHz
100mHz 10.0000kHz-99.9999kHz
1Hz 100.000kHz-999.999kHz
10Hz 1.00000MHz-2.00000MHz
Test Level:
+ Voltage Range: 5mVrms-2Vrms
+ Accuracy: ± (10%*Setting Value+2mV)
+ Resolution: 1mVrms: 5mVrms-1Vrms
10mVrms: 1Vrms-2Vrms
Vgs
+ Range: 0 - ±40V
+ Accuracy: 1%* Setting Voltage+8mV
+ Resolution: 1mV: 0V - ±10V
10mV: ±10V - ±40V
Vds
+ Range: 0 - 1500V
+ Accuracy: 1%* Setting Voltage+100mV
Boot Warm-up Time: 60 Minutes
Input voltage: 100-120VAC/198-242VAC Option, 47-63Hz
Power consumption: More than 130VA
Dimensions (W*H*D): 430*177*405
Weight: 12kg
