Tormach 24R CNC Router

Travels: X-Axis: 24.75 in. (625 mm); Y-Axis: 55.75 in. (1415 mm); Z-Axis: 6.70 in. (170 mm)

Spindle Power: 2 hp / 1.5 kW

Spindle Type: Electrospindle

Minimum Speed: 10,000 RPM

Maximum Speed: 24,000 RPM

Cooling: Water-Cooled (Chiller Included)

Spindle Taper: Stock - ER20; With ATC - ISO20

Thread Machining: Thread Mill

Power Required: 24R CNC Router: Single-Phase 115 VAC, 50/60 Hz, 15A Breaker

Power Required for Storm Vacuum Pump: Single-Phase 220-240 VAC, 20A Breaker

Table Type: Integrated Vacuum Table

Table Size: 26.5 in. × 65 in. (680 mm × 1650 mm)

Gantry Clearance: 6 in. (154 mm)

Machine Footprint: 72 in. × 39 in. (1.8 m × 1 m)

Overall System Height: 76.5 in. (1.9 m)

Typical System Weight: 900 lb (408 kg)

Axis Motion: Ballscrew and Stepper Driver

Guideways: Precision Linear Guideway

Maximum Feed Rate: 200 IPM (5.0 m/min)

Stand: Welded Steel (Included)

Machine Base: Cast Iron

Gantry: Aluminum

Resolution: 0.00025 in. (0.006 mm)

Ball Screw Positional Accuracy: ±0.002 in./ft. (±0.167 mm/m)

Repeatability: ±0.001 in. (±0.02 mm)

Certificate of Inspection: Available

PATHPILOT® Controller: Easy-to-learn, touch-screen-friendly user interface

Axis Support: Supports up to four-axis continuous machining

Programming: Intuitive conversational programming

Speeds and Feeds Calculator: Built-in recommended speeds and feeds calculator

Program Memory: 80GB

Software Updates: Free PathPilot® updates for life
