Width: 9.9 mm
Height: 2.3 mm
Length: 10.38 mm
Fall Time: 4 ns
Rise Time: 20 ns
Technology: Si
Unit Weight: 750 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 47 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 230 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 50 ns
Typical Turn-Off Delay Time: 100 ns
Id - Continuous Drain Current: 30 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 70 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 4 V
