Line Voltage: 200/230V
Output Voltage Range: 0 to ±30 kV DC or peak AC
Output Current Range: 0 to ±20 mA DC or ±40 mA peak AC
Input Voltage Range: 0 to ±10 V DC or peak AC
Input Impedance: 50 kΩ, nominal
DC Voltage Gain: 3000 V/V
DC Voltage Gain Accuracy: Better than 0.1% of full scale
Offset Voltage: Less than ±4 V Điện áp dòng:
Output Noise: Less than 5 V rms*
Slew Rate (10% to 90%: Greater than 725 V/µs
Settling Time: Less than 200 µs for a 0 to 0-30 kV step
Large Signal Bandwidth (2% distortion): DC to greater than 3.5 kHz
Small Signal Bandwidth (2% distortion): DC to greater than 25 kHz
Dimensions: 103.9 cm H x 43 cm W x 87 cm D
Weight: 73 Kg
