Luminance [cd/㎡]: 10 registered brightness points, 300–1,700
Standard brightness levels: 300, 500, 600, 750, 900, 1000, 1200, 1250, 1400, 1500
Luminance surface (WxH) [mm]: 140×110
Brightness uniformity [±%]: 2.5
Correlated color temperature [K]: 3200±150, 5500±500, 6500±500 (choose two colors)
Light source: LED
Lighting method: DC
Function: Registered brightness variable; Brightness adjustment function; LED lighting OFF function; Brightness feedback function; Auto calibration (requires LC-5)
Display / Operation: Main unit operation; Dedicated PC software; External communication control (serial)
Communication I/F: USB 2.0 compliant
Power supply voltage: AC100–240V, 50/60Hz
Power consumption [VA]: Under 100
Operating environment: Temperature 20–30°C (±2°C recommended); Humidity ≤80%, no condensation
Dimensions (WxHxD) [mm]: 186×194×68
Weight [g]: 600
Accessories: Dedicated PC control software; Chart folder
Extension functions: Color temperature setting; Brightness range change (5.7× from 90–3,000); Brightness range expansion; Pulse lighting (internal/external); Increased number of brightness registration points (up to 20 points)
