Fall Time: 2 us
Rise Time: 2 us
Output Type: NPN Phototransistor
Mounting Style: Through Hole
Isolation Voltage: 15000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 10 mA
Vf - Forward Voltage: 1.5 V
Vr - Reverse Voltage: 3 V
Current Transfer Ratio: 20 %
Pd - Power Dissipation: 250 mW
Maximum Collector Current: 50 mA
Current Transfer Ratio - Min: 20 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 25 V
Maximum Collector Emitter Saturation Voltage: 500 mV
