Width: 59.7 mm
Height: 43.2 mm
Length: 80 mm
Industry: Industrial
Approvals: EN/IEC/UL 62368-1
Dimensions: 80 mm x 59.7 mm x 43.2 mm
Efficiency: Level VI
Output Power: 130 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Screw
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC, 5.656 kVDC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 10.833 A
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 30 C
