Width: 10.2 mm
Height: 1.9 mm
Length: 15 mm
Antenna: Integrated
Protocol: BLE, Bluetooth 5.0
Data Rate: 2 Mb/s
Frequency: 2.43 GHz
Sensitivity: - 93 dBm
Unit Weight: 1.479 g
Output Power: 8 dBm
Interface Type: I2C, I2S, SPI, UART, USB
Mounting Style: SMD/SMT
Frequency Range: 2.36 GHz to 2.5 GHz
Moisture Sensitive: Yes
Modulation Technique: GFSK, QPSK
Receiver Sensitivity: - 93 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.7 V
Operating Supply Voltage: 1.7 V to 3.6 V
Supply Current Receiving: 9.9 mA
Supply Current Transmitting: 32.7 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
