Bandwidth : 350MHz
Channels : 4
Sample rate (analog) : 5 GSa/s (interweave mode),2.5 GSa/s (non-interweave mode)
Sample rate (digital): 1.25GSa/s
Memory depth : 500Mpts
Max. Waveform capture rate : ≥800,000 wfms/s;≥2,000,000 wfms/s (sequence mode)
Time base scale : 350 MHz (1 ns/div - 1 ks/div) 500 MHz (500 ps/div - 1 ks/div)
Input impedance : (1 MΩ±2%) || (16 pF±3 pF)
Input impedance (digital) (: 101 kΩ±1%)||(9 pF ± 1 pF)
Vertical scale : 500 μV/div - 10 V/div(1 MΩ) 500 μV/div -1 V/div(50 Ω)
DC gain accuracy : <5 mV : ±3% full scale,≥5 mV : ±2% full scale
Waveform record : 250,000 frames
Serial protocol analysis : Standard:RS232/UART, I2C, SPI Option:CAN, CAN-FD, LIN, FlexRay, AUDIO, MIL-STD-1553B, Manchester, SENT, ARINC429
Auto measurements : 54 kinds of parameter, simultaneously display 27 kinds of parameter measurement
Measurement statistics : Mean, Maximum, Minimum, Std Dev, Count, Tendency chart, Histogram
Arbitrary waveform generator (optional) : 2 CH, 50 MHz , 250 MSa/s
Frequency counter : 7-digit hardware frequency counter
Digital voltmeter : 4digits,DC/AC RMS/DC+AC RMS
Advanced analysis function : Power Analysis (Optional), BODE Plot (Optional), Limit Mask Testing
Standard interfaces : USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail, DVM), Gen Out, HDMI,WIFI, 10MHz reference clock IN/OUT
Standard Accessories
Power cord conforming to the standard of the destination country
UT-D30: USB3.0 data cable
UT-P07A/UT-P08A: Passive probe x 4 (1 x, 10 x switchable, 500 MHz/350 MHz)
UT-L45: BNC-BNC straight-through cable ×1
UT-L02: BNC-red and black alligator connecting wire x 1
