UNI-T UT151F Modern Digital Multimeter (600VAC/DC, 10AAC/DC)

Cerificate: CE/UKCA/cETLus/RoHS

Safety Category: CAT III 600V

DC Voltage (V): 200mV/ 2V/ 20V/ 200V/600V: ±(0.05%+3)

AC Voltage (V): 200mV/2V/ 20V/ 200V/600V: ± (0.5%+10)

DC Current (A): 2mA/ 20mA/ 200mA/ 10A: ± (0.5%+5)

AC Current (A): 2mA/ 20mA/ 200mA/ 10A: ± (0.8%+10)

Resistance (Ω): 200Ω/ 2KΩ/ 20KΩ/ 200KΩ/ 2MΩ/ 20MΩ: ±(0.3%+1)

Capacitance (F): 20nF/ 200nF/ 2μF/ 20μF: ±(4%+20)

Frequency (Hz) 20KHz: ±(1.5%+5)

Power: 9V Battery（6F22)

LCD Size: 63mm X 29 mm

Product Color: Red and Grey

Product Net Weight: 300g

Product Size: 186mm X 91mm X39 mm

Standard Accessories: Battery, Test Lead, English Manual

Features:

Display Count: 20000

Manual Range: √

Battery Test: No

Diode: √

Auto Power Off: √

Continuity Buzzer: √

Low Battery Indication: √

Data Hold: √

Input Impedance for DCV ≥10MΩ: √

True RMS: No

Backlight: No

Min/Max: No
