Display mode: Visual numerical reading, bar chart and curvilinear graph
Index No.: Thermocouple: J,K,T,E,S,N,B,R
Measuring range: -200℃~1800℃ (varies with different thermocouple)
Resolution: 0.1℃
Number of channel: 24
Scanning speed: Fast, slow
Sorting function: Build-in data sorting, can set upper/lower temperature limit alarm for each channel
Alarm function: Upper/lower temperature limit alarm
User calibration: User calibration of each channel is allowed
Button functions: Lock -keyboard lock, Print Sc -screenshot
System setup Language: Chinese/English, key tone setting
Storage: FAT storage function (supports USB disk storage, mobile hard disk drive is not supported)
Interface & protocol: RS-232 and USB communication interface, SCPI protocol
Upper computer software: Yes
Display mode: Test temperature range / Accuracy
- T-type Thermocouple: -150℃-0℃, 0℃~400℃ / ±1℃, ±0.8℃
- K-type Thermocouple: -100℃-0℃, 0℃~1350℃ / ±1.2℃, ±0.8℃
- J-type Thermocouple: -100℃-0℃, 0℃~1200℃ / ±1℃, ±0.7℃
- N-type Thermocouple: -100℃-0℃, 0℃~1300℃ / ±1.5℃, ±0.9℃
- E-type Thermocouple: -100℃-0℃, 0℃~850℃ / ±0.9℃, ±0.9℃
- S-type Thermocouple: -100℃-0℃, 100℃~300℃, 300℃~1750℃ / ±4.5℃, ±3℃, ±2.2℃
- R-type Thermocouple: 0℃-100℃, 100℃~300℃, 300℃~1750℃ / ±4.5℃, ±3℃, ±2.2℃
- B-type Thermocouple: 600℃-800℃, 800℃~1000℃, 1000℃~1800℃ / ±5.5℃, ±3.8℃, ±2.5℃
Power: AC 100~240V; 50/60Hz
Display: 4.3-i nch LCD screen
Product net weight: 3.5kg
Product size (WxHxD): 340mm X 214mm X 89mm
Standard accessories:
- Power cord conforming to the standard of the destination country
- USB interface cable x1
- 8G U-disk x1
- Channel identifier x1
- (UT3208/16/24/32 correspond to 1/2/3/4 set of test lead)
- K-type test lead temperature range: -100~200℃
- UT-T21M: K-type thermocouple test lead module
Optional accessories: Thermocouple sensor: T,J,Z,N,S,E,B,R,and many more
