Channels: 2
Bandwidth: 70MHz
Sampling rate: 500MS/s
Rise time: ＜5ns
Memory depth: 64kpts
Waveform capture rate: >5000wfms/s
Vertical scale (V/div): 1mV/div~20V/div
Time base scale (s/div): 2ns/div~50s/div
Timing accuracy: ≤± (50+2 × service life)ppm
Timebase mode: Y-T, X-Y, Roll
Storage methods: Setup, wave, bitmap
Trigger types: Edge, pulse width, Slope, video, alternate
Mathematical operations: ＋, －, ×, ÷, FFT
Auto measurements: Max, Min, High, Low, Ampl, Pk-Pk, Middle, Mean, CycMean, RMS, C ycRMS, Period, Freq, Rise, Fall, RiseDelay, FallDelay, +Width, -Width, +Duty, -Duty,(UTD2052/25CL)FRR, FRF, FFR, FFF, LRF, LRR, LFR, LFF, Area, CycArea, OverSht, PreSht, Phase, 34 parameters in total
Displayed measurements: Display 5 measurements at the same time
Frequency counter: 6 bits
Interface: USB OTG, Pass/Fail
Power: 100-240VAC, 45-440Hz
Display: 7 inches TFT LCD, 800×480
Product color: White and grey
Product net weight: 2.5kg
Product size: 306mm×138mm×124mm
