Technical Data
IR resolution (Pixels): 160×120
Display: 2.8” TFT LCD (320×240)
Field of view(FOV): 56°×42°
Thermal sensitivity(NETD): ≤50mk
Spatial resolution(IFOV): 6mrad
Frame rate: ≤9Hz
Focus: Focus free
Temperature measurement range: -10℃~400℃
Accuracy: ±2℃ or ±2% whichever is greater
Emissivity: 0.01~1.00 adjustable(0.95 default)
Functions
Color palettes: 5 (White hot, Red hot, Ice blue, Rainbow, Ironbow)
Image modes: Thermal,Visual image,Fusion
Hi/Lo temperature alarm: Icon,LED flashlight
PC software analysis: Yes
General Characteristics
Battery: Fixed Li-ion battery (3.6V 5000mAh)
Battery operation time: ≥ 6 hours
USB: Type-C
IP rating: IP65
Drop proof: 2m
Storage: Up to 32GB Micro SD card
Image/Video storage format: BMP
Certificates: CE,RoHS
Product net weight: 910g
Product size: 236mm×75.5mm×86mm
Packing Details
Standard accessories: Micro SD card, Type-C USB cable, Adapter, English manual
