Technical Data
Display: 4.3” LCD Touch (800×480)
IR resolution(Pixels): 640×480
Super resolution: √(1280×960)
Spectral range: 7.5~14μm
Pixel size: 12μm
Frame rate: 30Hz
Thermal sensitivity(NETD): ≤40mK
Focus: Manual / Automatic / Touch autofocus / Continuous autofocus
Lens recognition: Automatic
Infrared lens:Lens focal lengthField of view(FOV)
Standard lens17.7mm25°×19°
Marco lens (Optional)16.2mm/
Wide-angle lens (Optional)10.0mm44°×34°
Medium tele lens (Optional)29.0mm15°×11°
Tele lens (Optional)62.9mm7°×5°
High-temp lens (optional)/25°×19°
Temperature measurement range: Support auto-switching: -40°C~150°C, 0°C ~650°C; 500°C ~2000°C (Optional Hi-temp. Lens)
Accuracy: ±2℃ or ±2% whichever is greater
Functions
Color palettes: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized
Image modes: Thermal, Visual image, Fusion, PIP
On screen analyzer: 16 Points/16 Lines/16 Rectangles/16 Circles
Isotherm: Automatic, Semi-automatic, Manual
Level & Span: √
Image outline: √
Panoramic stitching: √
Hi/Lo temperature alarm: LCD animation, LED flashlight, Buzzer
Hi/Lo temperature tracking: √
All-around voice assistant: √
Annotation: Text, Voice, Image
Digital camera resolution: 13MP
Digital zoom: 1.1x~20x
Video recording: √
Voice recording: √
Wi-Fi / Wi-Fi live streaming: √
Bluetooth: √
GPS: √
Laser pointer / LRF: √
LED lighting: √
Analysis software: PC+APP
General Characteristics
Battery: 3350mAh detachable Li-ion battery pack
Operating time: ≥4 hours (with Wi-Fi off)
USB: Type-C
Storage: 64GB Internal & 64GB Micro SD card
Image storage format: Jpg
Video storage format: MP4 & Irgd
Protection: IP54 & 2m
Languages: ZH_hans, ZH_hant, EN, FR, DE, ES, IT, RU, PL, KR, PT, TR, TH, NO, CZ, HU, JP, AR
Weight: ≤1.15KG (included standard lens & battery)
Dimension: 292mm×125mm×125mm
