Cable Length Measurement:
Length : 2-400m
Resolution: 0.1m
Best Accuracy : ±(1%+2m)
Digitalized Cable Tracing: Yes
Tracing cables connected to ethernet hub with PoE support: Yes
Port Blink Test 10M/100M/1000M: Yes
Identify wire Pairs and quality of wire connections: Yes
PoE Voltage Polarity Checking: Yes
PoE Voltage measurement (for reference only): Yes
Remote Identification (Optional) : Max 15
Crimping Crystal Test: Yes
Intelligent Wiremap: Yes
Shorts: Yes
Split Pair: Yes
Breakpoint checking: Yes
Continuity Test: Yes
Battery Test 0-60V : for reference only
NCV: Yes
Analogue Bargraph: Yes
Tracing signal transmission distance : 3Km
Output signal level: ~15Vp-p
Vibration inducation: Yes
Flashlight (both main body & transmitter): Yes
Sensitivity Adjustable: Yes
Input Jack Indicator: Yes
Low Battery Indication: Yes
Auto Power Off: Yes
Working on Network Cable (8P8C, 4P4C), Phone Line and Coaxial Cable: Yes
User Calibration: Yes
Multimeter:
DC Voltage 6V~1000V: ±(0.5%+3)
AC Voltage 6V~750V: ±(1%+3)
DC Current 600mA~10A: ±(1.2%+3)
AC Current 600mA~10A: ±(1.5%+3)
Resistance 600Ω~60MΩ: ±(1.5%+3)
Diode: P
Continuity: P
Frequency 6Hz~6MHz: ±(0.2%+3)
Capacitance 6nF~60MF: ±(5%+20)
Max Display : 6000
Display Mode : Vertical Alignment
Power by : Transmitter : 3.7V 1250mAH Lithium ion; Receiver : 9V (6F22)
