DC V: 200mV/2V/20V/200V/1000V
Accuracy: ±(0.05% +10)
AC V: 200mV/2V/20V/200V/1000V
Accuracy: ±(0.5% +40)
DC A: 200uA/2000uA/20mA/200mA/2A/10A
Accuracy: ±(0.2%+10)
AC A: 200uA/2000uA/20mA/200mA/2A/10A
Accuracy: ±(0.8%+30)
Resistance: 200Ω/2ΚΩ/20ΚΩ/200 ΚΩ/2ΜΩ/20ΜΩ/60ΜΩ
Accuracy: ±(0.2% +5)
Capacitance: 10nF/100nF/1000nF/10uF/100uF/1000uF/10mF/100mF
Accuracy: ±(5%+5)
Frequency: 10Hz/100Hz/1000Hz/10kHz/100kHz/1000kHz//5MHz
Accuracy: ±(0.02%+4)
Thermocouple (K index):(-200.0-1372.0)°C
Accuracy: ±(0.5%+3°C)
RTD (Pt100):(-200.0-850.0)°C
Accuracy: ±(0.5%+3°C)
Features
Max Display: 22000
Sampling Rate: 3 times/s
Analog Bar Graph: 20 times/s
Operation Way: Automatic / Manual Range
True RMS: √
Bandwidth: 1kHz
Duty Cycle: 10%～90%
Diode test: √
Continuity beeper: √
dBm: √
MAX/MIN/AVG: √
Relative Value Measurement: √
Data Hold: √
Auto Hold: √
Peak Hold: √
The reference junction compensation: √
°C/ ° F conversion: √
Input impedance: 10MΩ
Data Recording: 2000 group
Auto power-off: √
Backlight: √
