Electrical Properties
Passband (MHz): 4000 - 4200
Group Delay Variation: 1.45 nSec Max within ±0.5 MHz
Insertion Loss – Typical (dB): 1.1
Insertion Loss – Max (dB): 1.3
Rejection:
70 dB Min below 3900 MHz
60 dB Min at 3980 MHz
50 dB Min at 3983 MHz
25 dB Min above 4230 MHz
Return Loss: 20 dB Min
Mechanical Properties
Interface Flanges: CPR229G / CPR229F - Thru holes
Material: Aluminum 6061
Finish:
Flanges: Chemical Conversion
Waveguide: Silver Plate
Exterior: Paint
Weight: 2.2 lbs (998 g)
Operating Temperature: -40°C to +50°C
