Vishay Draloric PE0100WH30133BH1 RF Power Plate Capacitors Contoured Rim, Class 1 Ceramic PE100 13KVP 300pF +/-5% R42 1019

Name: Vishay Draloric PE0100WH30133BH1 RF Power Plate Capacitors Contoured Rim, Class 1 Ceramic PE100 13KVP 300pF +/-5% R42 1019
Brand: Vishay Draloric

ManufacturerVishay Draloric(View more products from this manufacturer)

ModelPE0100WH30133BH1

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Class: 1

Length: 40 mm

Diameter: 100 mm

Tolerance: 5 %

Dielectric: R42

Capacitance: 300 pF

Voltage Rating: 13 kVDC

Capacitance - nF: 0.3 nF

Termination Style: Screw

Voltage Rating AC: 13 kVAC

Voltage Rating DC: 13 kVDC

Dissipation Factor DF: 0.05

Operating Temperature Range: - 55 C to + 100 C

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 55 C
