Fall Time: 21 ns
Rise Time: 20 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N Channel
Qg - Gate Charge: 196 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 266 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 20 ns
Typical Turn-Off Delay Time: 78 ns
Id - Continuous Drain Current: 504 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 160 S
Rds On - Drain-Source Resistance: 870 uOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.2 V
