DC Bias: Current Output Current 0 to 25 Amps DC in 10 mA steps.
Current when stacked 250 Amps DC with 10 x DC1000A
DC Bias: Current Output Accuracy of DC Current ±0.5% of reading ±25 mA.
Compliance voltage 5 Volts
Effect on the LCR measurement Typically <10uA per Volt, for 20 Hz-10 MHz LCR conditions. See User Manual for full error specification
Environmental Specifications : Temperature +5°to + 40°C operating
Humidity : 10% to 80% RH non-condensing
Power Supply to Case : 2.9 kV DC for 1 minute
Power Requirement : 100-125 V / 200-250 V AC 48-65 Hz. 400 VA Max.
Fuse : 3.15 AT
Mechanical : H x W x L 88 mm x 475 mm x 255 mm
Weight : 10 kg
Mounting : Bench or 19" Rack mounting
Interfaces : RS232 Remote control
Safety Interlock : Connection to operator safety system if required. Override plug Supplied.
Protection : Open circuit : Warning LED.
Over temperature : Auto-Shutdown and warning
Back -EMF (over voltage) : protects DC1000A and LCR meter
Variable Speed Cooling Fan
