Features:
CCD Imager with Integrated Illumination
USB interface to PC
ISO grading
Data export to printer, PDF file or Excel
Software easily upgradeable
Calibrated to NIST traceable standards
Symbology: Data Matrix, QR Code, RSS
Light Source: Narrow band 660nm LED
Standard Imager 45° Illumination for labels
DPM Imager 30° and specular Illumination
Decoding/Grading Analysis Specifications
Full ISO 15415 Grading A, B, C, D, F:
Unused Error Correction, Modulation, Axial nonuniformity, Grid non-uniformity, Symbol
Contrast, Reference Decode, Finder Pattern
Damage, Bar Width Growth (X and Y), Quiet
Zone
AIM DPM Grading: Cell Contrast, Cell Modulation
Specification Conformance:
MIL-STD 130N ISO 16022
ISO 15415 AIQG AS9132
AIM DPM ISO 15426-2
Environment
Temperature: 0-40°C
Humidity: 5% - 95% noncondensing
Physical
Remote Dimensions: 7.25” x 6.50” x 7”
