Flow Range: 10-400 LPM
Pressure Range: 0-420 bar
Fluid Temperature Range: 0 - 105°C
Inlet/Outlet Ports: 1” BSPP
Functional specification
Ambient temperature: 5 to 40°C (41-104°F)
Fluid type: Hydraulic oil
Accuracy: Flow: ± 1% of indicated reading (15 to 100% of range)
Pressure: ± 0.5% full scale
Temperature: ± 1°C (± 2°F)
Power: Below 100KW (134HP) ± 3KW (± 4HP)
Above 100KW (134HP) ± 5KW (± 6.7HP)
Volumetric efficiency: ± 1%
Data Recording: up to 12 sets of data points can be saved to internal memory
Peak Pressure: is sampled 1000 times/second.
Battery Life: approximately 15hours continuous with high capacity Alkaline unit.
IP54 Internal Protection of electrical circuits.
Dimensions in mm (inches): 240 (9.45”) wide, 200 (7.87”) deep, 200 (7.87”) high
Weight: Unpacked 6.5Kg (14lbs)
Construction materials
Case: Powder coat painted mild steel
Flow block: High tensile aluminium
Seals: Viton as standard - EP seals on request
