Inputs (Number and type of sensors): 2 ‘SR’ sensors – up to four channels
- Functional specifcation:
Operating temperature: 0 to 50 °C (32 - 122 °F)
Degree of protection:
HPM4020 – IP54 (EN60529)
- Electrical specifcation:
Internal battery: Lithium ion pack 3.7 VDC/HPM4020-2250mAh
Battery life with 2 sensors: > 8 hours
External power supply: Input -100-240 VAC
Connection type: Micro-USB socket, Type B, +5 VDC max 1000mA
- Memory:
Internal memory: 1 measurement – approx.. 15,000 data records
USB memory stick: 1GB supplied – supports up to 4GB
- Interfaces:
USB device:
Online data transfer between device and PC via HPMcomm software; measured value transfer: ACT/MIN/MAX, min. 5 ms; USB standard: 2.0, full speed; connection assembly:
Micro USB socket, protected, type B
USB host: Connection of USB memory stick, max. 4 GB; recommended types: Delock USB 2.0
Nano memory stick,Intenso Micro Line; USB standard: 2.0, full speed, max. 100 mA; connection assembly: Micro USB socket,protected, type B
- Display:
Type: FSTN-LCD, graphical, with LED background lighting
Visible area, mm (inches): 62 x 62 (2.4 x 2.4)
Resolution: 130 x 130 pixels
- Construction material:
Housing material: ABS/PC
Housing protective shield: TPU
Dimensions, w x h x d, mm (inches): 96 (3.8) x 172 (6.8) x 54 (2)
Weight: 540 grams
