Max dia.swing over bed(mm): 1000
Max dia.swing over cross slide(mm): 610
Max.length of work-piece(mm): 1500/3000/4000/5000
Width of bed(mm): 755
Spindle bore(mm): 360
Power of spindle motor: 22kW
Mode of spindle speed: Two gears, smooth adjustment
Range of spindle speed(r/min):(L): 30-130, (H): 65-260
Max.traverse of X/Z(mm): X:550; Z:1250
X/Z rapid traverse(r/min): 4000
X-axis motor
Speed(r/min):1500
Torgue(N.m): 18
Power(kw): 2.8
Z-axis motor
Speed(r/min): 1500
Torgue(N.m): 22
Power(kw): 3.5
Tailstock quill
Diameter(mm): 140
Travel(mm): 300
Taper: Morse NO.6
Electric tool-post
Model: SLD170A04N
No.of tool stations: Vertical four-station
Dimension(mm): 300x300
Chuck: K66-850 four jaw chuck
Positioning accuracy(mm): 0.02
Overall dimensions(L*W*H)(mm): 5000×2100×2100
Machine weight(kgs): 12000
