Worktable size (LxW): 1400x700mm
T-slot (NxWxD): 5x18x115mm
X/Y/Z axis travel: 1300/700/700mm
Distance from spindle center to column: 775mm
Distance from spindle nose to worktable surface: 103-803mm
Spindle taper: BT50
Spindle power: 11/15kw
Max.spindle speed: 6000rpm
Max.feed speed: 10m/min
Rapid feed speed (X/Y/Z): 24/24/15m/min
X/Y/Z axis ball screw: 4012
Tool change time (T-T): 3s
Positioning accuracy (X/Y/Z): ±0.010mm
Re-positioning accuracy (X/Y/Z): ±0.005mm
LxWxH: 3330x2880x3250mm
Max.loading of worktable: 1000kgs
Machine weight: 11000kg
