Worktable size (LxW): 2000x900mm
T-slot (NxWxD): 5x22x165mm
X/Y/Z axis travel: 1800/900/600mm
Distance from spindle center to column: 950mm
Distance from spindle nose to worktable: 180-980mm
Spindle taper: BT50
Spindle power: 18.5/22kw
Max.spindle speed: 6000rpm
Max.feed speed: 10m/min
Rapid feed speed (X/Y/Z): 15/15/12m/min
X/Y/Z axis ball screw: 5512
Tool change time(T-T): 3s
Positioning accuracy (X/Y/Z): ±0.012mm
Re-positioning accuracy (X/Y/Z): ±0.008mm
LxWxH: 5500x3700x4100mm
Max.loading of worktable: 1200kgs
Machine weight: 16000kg
