Fall Time: 4 ns
Rise Time: 6.5 ns
Technology: SiC
Unit Weight: 1.600 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 9.5 nC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 50 W
Vgs - Gate-Source Voltage: - 8 V, + 18 V
Typical Turn-On Delay Time: 10.5 ns
Typical Turn-Off Delay Time: 11 ns
Id - Continuous Drain Current: 11 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 3.1 S
Rds On - Drain-Source Resistance: 385 mOhms
Vds - Drain-Source Breakdown Voltage: 900 V
Vgs th - Gate-Source Threshold Voltage: 1.8 V
