Impedance: 50 Ohms
RF Series: TNC
Body Style: Right Angle
Body Finish: Nickel
Orientation: Right Angle
Body Material: Brass
Mating Cycles: 500 Cycles
Insertion Loss: 0.25 dB
Mounting Style: Cable Mount / Free Hanging
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 6 GHz
Minimum Frequency: DC
Termination Style: Crimp
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
