Motion System
+ Motion System: High Precision Servo System
+ Resolution: X axis: ±0.02mm; Y axis: ±0.02mm; Z axis: ±0.02mm; θaxis: ±0.1°
+ Stroke: X axis: 1000mm; Y axis: 500mm; Z axis: 40mm
+ Pick & Place Header Accuracy: ±0.07mm
+ Operable Chip Size: Minimum: 2x2mm; Maximum: 25x25mm
+ Maximum Throughput: 1200 Units Per Hour
Vision System:
+ Camera: Downward CCD camera for sockets / pick & place spots positioning. 512×512 pixels
+ Field of View: 30x30mm
Power Consumption: 1.5KVA
Air:
+ Pressure: 0.6MPa
+ Consumption: 30 liters/min
Size:
+ Main Machine: 820(L)×640(W)×1550(H)mm
+ Auto Tray: 1100(L)×380(W)×1300(H)mm
+ Tape-Out: 1100(L)×380(W)×1300(H)mm
Weight: Main machine: 248kg
PC Interface: USB 2.0, LAN
Included accessories:
+ 4 x SuperPro 7500
+ Built-in Industrial PC with Windows 7
+ 19" LCD Display
+ Keyboard and mouse
Optional accessories:
+ Socket Adapters (Socket Pressing)
+ Automated Tray Handler
+ Tape-out Packing Handler
+ Electric Tape-in Feeder
+ Laser Marker
+ Tube In Device
+ Tube Out Device
+ Tape Ink Marker
+ Auto Tray Ink Marker
+ Nozzles
