3rd Party Software Supported: X-Rite InkKeyControl, eXact Manager, NetProfiler, and third party scanning integrators
Aperture: eXact Auto-Scan supports 1.5mm & 2mm
Battery: Lithium Ion, 7.4VDC, 2200mAh
BestMatch Feature: Yes
Black Background With Sheet Storage: Black Background
Calibration: Automatic on integrated white reference
Closed Loop Support: Yes
Color Bar Alignment: Laser
Color Differences: CIE ∆E* (1976), ∆ECMC, CIE ∆E* (2000), and CIE ∆E* (1994)
Color Spaces: CIE L*a*b*, CIE L*C*h°, CIE XYZ and Yxy
Communication Interface: USB 2.0; Bluetooth (optional) - Class II
Density Range: 0.00 D – 3.00 D
Density Standards: Status A, E, I, T and G
G7 Certification: Yes with embedded G7, PSO, JapanColor job templates
Humidity: 30% to 85% RH (non-condensing)
Illuminants: A, C, D50, D55, D65, D75, F2, F7, F11, D12
Import/Export Format: CxF3, SDF, SVF, TVF
Industry Standards: ISO 5-4:2009(E), ISO 13655:2009
Instrument Display: Color touch-screen, 320 x 240 pixels
Inter-Instrument Agreement: 0.3 dE*ab
Internal Temperature & Humidity Sensor: Yes
Languages Supported: Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish, Turkish, Vietnamese
Light Source: Gas filled tungsten (illuminant type A) and UV LED
Measurement Conditions: M0, M1 (part 1), M1 (part 2) , M2, M3
Measurement Geometry: 45°:0° ring illumination optics, ISO 5-4:2009
Measurement Spot: eXact Auto-Scan supports 1.5mm & 2mm
Media Thickness: 1mm or less
NetProfiler Support: Yes
Operating Temperature Range: 10°C to 35°C; 50°F to 95°F
Pass / Fail: Yes
Patch Size: 3mm minimum with 1.5mm aperture
Scan Length: 29" (74 cm) or 40"(102 cm) maximum length depending on track size
Scanning Speed: 7" / sec (160 mm / sec)
Single Pass Scan: Yes
Software Development Kit: Yes
Spectral Analyzer: DRS Spectral Engine
Spectral Range: 400 nm to 700 nm
Storage Temperature Range: -20° to 50°C, -4° to 122°F
Track Sizes: 29" (74cm) or 40"(102cm)
Unit Color: Black/Silver
Voltage: 12 VDC tại 2.5 A
What's Included?: Track, power supply, interface cables, eXact Standard or Advanced with Scan and BlueTooth (if purchased), InkKeyControl software (if purchased) and documentation, guide, carrying case, device certificate
Windows: Windows XP (32bit), Windows 7 (32 and 64 bit), Windows 8 (32 and 64 bit), Windows 10 (32 and 64 bit)
