System: Forced air circulation
Operating temperature range: RT +10 to 260°C
Temp. control accuracy: ±0.2°C (at 260°C) JTM K05
Temp. distribution accuracy: ±2.0°C (at 260°C) JTM K05
Max. temp. reaching time: Approx. 55 min
Interior/Exterior material: Stainless steel /Electro-galvanized steel sheet with epoxy and melamine resin baking finish
Heater/heat insulator: SUS pipe heater / glass wool
Heater capacity: 200 to 240V / 2.7 to 3.88 kW
Fan type / Motor: Scirocco fan / Condenser type motor
Cable port: 30mm I.D. (the right) 1pc.
Door packing: Fluoroelastomer
Air in-take port: One on the side (heater room side)
Exhaust port: I.D. 30 mm (with damper) × 2 (the back)
Temp. controller: SSR control
Internal dimensions (W×D×H): 770×696×1,760mm
External dimensions (W×D×H): 600×500×1,000mm
Internal capacity: 300L
Power supply: Single phase: AC200 to 240V, 12.5 to 15A
Weight: 130 kg
