Rated Current:1/5A
Rated Voltage:120V (Used between 60 and 300 V.)
Operating Principle:Rectifier type
Class:JIS C 1102 : 1997 Class 3.0
Operating Position:Horizontal
Rated Frequency:45 ~ 65 Hz
Scale Length:Approximately 135 mm (Deflection Angle: 85°)
Scale:Lead 0-0.3 to 1.0 to 0.3-0 lag (with phase angle scale)
Effective Measurement Range:Lead 0.5 to 1.0 to 0.5 lag
Approx. Consumed Power Voltage Circuit (120 V):0.14 VA
Approx. Current Circuit (5 A):2.4 VA
Operating Temperature Range:0 ~ 40°C
Operating Humidity Range:30 ~ 75% RH
Storage Temperature Range:-10 ~ 50°C
Storage Humidity Range:25 ~ 80% RH
Dimension:260 x 180 x 115 mm
Weight:2.9 kg
