Wavelength: 1650 ±5 nm, 1650 ±10 nm
Pulse optical output: +15 dBm or less
Event dead zone: 0.6 m, 0.7 m
Attenuation dead zone: 4 m
Dynamic range: 40 dB, 37 dB
Distance range: 200 m, 500 m, 1 km, 2 km, 5 km, 10 km, 20 km, 30 km, 50 km, 100 km, 200 km, 300 km, 400 km, 512 km
Pulse width: 3 ns,10 ns, 20 ns, 30 ns, 50 ns,100 ns, 200 ns, 300 ns, 500 ns, 1 μs, 2 μs, 4 μs, 5 μs,10 μs, 20 μs
Distance measurement accuracy: ± (0.75 m + measurement distance x 2 x 10-5 + sampling resolution)
Loss measurement accuracy: ±0.03 dB
Sampling resolution: Min. 2 cm
Readout resolution: horizontal 1 cm (Min.),vertical 0.001 dB (Min.)
Number of sampling data: Max. 256,000 points
Group refractive index: 1.30000 to 1.79999 (0.00001 steps)
Unit of distance: km
Measurement functions: Distance, Loss, Return loss
Optical connector: SC (fixed)
Operating environment: Temperature: -10 to +50°C; Humidity: 0 to 90%RH or less (no condensation)
Altitude: 4000 m or less
Storage environment: Temperature: -20 to +60°C; Humidity: 0 to 90%RH or less (no condensation)
Power requirements: 12 V DC 2.5 A or less
Rated power supply voltage: 12 V ±10% DC
Warm-up time: 30 minutes or more
Dimensions: 230 (W) x 140 (D) x 50 (H) mm (excluding projections)
Weight: Approximately 1 kg
Accessories: User’s Manual 1 set
